Ion source | Flashover-type (passive) anode UV-radiation assisted (active) anode |
Accelerated ions | proton, carbon, fluorine, sodium |
Accelerating voltage | 0.4 MV |
Energy | 0.4 MeV for singly charged positive ions |
Beam current | 20 kA |
Pulse width | 60 ns |
High voltage generator | |
Marx generator | 8 stage, 5 kJ |
Pulse forming line | co-axial type with water dielectric, 3 ohms |
